【Replacing Lead-acid Batteries】: 48V 280Ah lithium batteries are used for golf carts, which can be used to replace or substitute lead-acid batteries. Long lifespan and strong endurance, 8 times that of lead-acid batteries. Fast charging, fully charged in 5 hours.
【Built-in 150A BMS】:High quality (Grade A EVE cells) Safety,150A BMS, full protection, touch LCD display for real-time battery status viewing ,Bluetooth APP, ONE-KEY for battery problem diagnosis.
PRODUCT INFORMATION
| Category |
Details |
| Voltage & Capacity |
- Nominal Voltage: 48V (Full Charge Voltage: 54.6V)
- Nominal Capacity: 280Ah
- Energy: 13.44kWh
- Chemistry: LiFePO4 (Lithium Iron Phosphate) / NMC (Optional) |
| Dimensions & Weight |
- Size: Customizable (Standard: 700×420×320mm, ±5%)
- Weight: 85kg (LiFePO4) / 70kg (NMC)
- Case Material: IP67-rated ABS + Aluminum Alloy (Dust/Waterproof)
- Terminals: M8 Brass Studs (Customizable to SAE/JIS Standards) |
| Discharging |
- Max Continuous Discharge Current: 300A
- Peak Discharge (10s): 600A
- Charging Current: 40A Standard (Supports 80A Fast Charging)
- Charging Time: 10-12h (Standard Charger)
- Discharge Temperature Range: -20 °C~55 °C (self heating optional) |
| Lifespan |
- Cycle Life(80% DoD): ≥4000 Cycles (LiFePO4)
- Calendar Life: 10 Years |
| BMS (Battery Management System) |
- 300A Smart BMS with Overcharge/Over-discharge/Short Circuit/Over-temperature Protection
- Bluetooth 5.0 & Wi-Fi (Optional) for APP Monitoring (iOS/Android) |
【Born For Golf Carts】: Compact structural design. Optimization and processing based on various well-known lithium battery compartments for golf carts. Easy to install, suitable for all 48V golf cart models such as Club Car, Yamaha, EZGO, and other brands.
【Package Includes】:48V 105Ah battery, LCD display and bracket, smart charger, AC extension port,screws.
【 Comprehensive After-Sales Service 】: 5-years warranty, US local warehouse, full support.
