Powerful Smart BMS: Comes with a 150A intelligent Battery Management System (BMS). It effectively protects the battery from over - charge, over - discharge, over - current, and short - circuit, extending the battery's lifespan and ensuring safe operation.
PRODUCT INFORMATION
| Category |
Details |
| Voltage & Capacity |
- Nominal Voltage: 48V (Full Charge Voltage: 54.6V)
- Nominal Capacity: 230Ah
- Energy: 11.04kWh
- Chemistry: LiFePO4 (Lithium Iron Phosphate) / NMC (Optional) |
| Dimensions & Weight |
- Size: Customizable (Standard: 650×400×300mm, ±5%)
- Weight: ~70kg (LiFePO4) / 58kg (NMC)
- Case Material: IP67-rated ABS + Aluminum Alloy (Dust/Waterproof)
- Terminals: M8 Brass Studs (Customizable to SAE/JIS Standards) |
| Discharging |
- Max Continuous Discharge Current: 250A
- Peak Discharge (10s): 500A
- Charging Current: 30A Standard (Supports 60A Fast Charging)
- Charging Time: 8-10h (Standard Charger)
- Discharge Temperature Range: -20 °C~55 °C (self heating optional) |
| Lifespan |
- Cycle Life(80% DoD): ≥4000 Cycles (LiFePO4)
- Calendar Life: 10 Years |
| BMS (Battery Management System) |
- 250A Smart BMS with Overcharge/Over-discharge/Short Circuit/Over-temperature Protection
- Bluetooth 5.0 & Wi-Fi (Optional) for APP Monitoring (iOS/Android) |
Smart Charger: Included is a smart charger that is designed to charge the battery efficiently. It automatically adjusts the charging current and voltage according to the battery's state, reducing charging time and improving charging efficiency.
Bluetooth and Proprietary APP: Equipped with Bluetooth technology and a dedicated APP, you can monitor the battery's status, such as charge level, voltage, and current, in real - time. The APP also allows you to set charging schedules and receive alerts for any potential issues.
Perfect Compatibility: Specifically designed for 48V golf carts, this BOPGA lithium - ion battery offers a direct replacement for your existing battery, providing reliable power and enhanced performance for your golfing adventures.
